Radial Velocity 3D Isosurface for 33 Million Stars From GAIA DR3 Data Visualization

by matt392 in Circuits > Computers

15 Views, 0 Favorites, 0 Comments

Radial Velocity 3D Isosurface for 33 Million Stars From GAIA DR3 Data Visualization

Radial Velocity 3D Isosurface for 33 Million Stars From GAIA DR3 Data Visualization

Created using Python and Claude.ai

30 Second Video Rotation: https://youtu.be/ZUqtpMxYCYE

"""

3D Stellar Density Radial Velocity Isosurface — Streaming Large Dataset Version

GAIA DR3 | ~33M stars

Streaming chunked loading — no all_chunks list — RAM-safe for any file size

"""

import os

import pandas as pd

import numpy as np

from scipy.ndimage import gaussian_filter

import pyvista as pv

import multiprocessing as mp

import time

import imageio

os.chdir(r'C:\temp')

# ╔══════════════════════════════════════════════════════════════╗

# ║ SETTINGS ║

# ╚══════════════════════════════════════════════════════════════╝

CSV_FILES = [

'33m-stars-radial-velocity.csv'

]

RA_COL = 'ra'

DEC_COL = 'dec'

PAR_COL = 'parallax'

MAX_DIST_LY = 32600

GRID_SIZE = 400

SIGMA = 1

N_CORES = 4

CHUNK_SIZE = 500_000

RING_DISTANCES = [500, 1000, 2000, 3262, 5000, 8000, 10000, 13000, 16000]

LABELS = []

OUTPUT_IMAGE = 'isosurface_1B_still.png'

RV_COL = 'radial_velocity'

ARROW_STRIDE = 8

RV_THRESHOLD = None # set after d_max is known — handled automatically

# ╔══════════════════════════════════════════════════════════════╗

# ║ MULTIPROCESSING WORKER ║

# ╚══════════════════════════════════════════════════════════════╝

def process_chunk_worker(args):

chunk, x_range, y_range, z_range, max_dist = args

chunk = chunk.copy()

chunk = chunk.dropna(subset=[RA_COL, DEC_COL, PAR_COL])

chunk = chunk[chunk[PAR_COL] > 0]

chunk['distance_ly'] = 3262.0 / chunk[PAR_COL]

chunk = chunk[np.isfinite(chunk['distance_ly'])]

chunk = chunk[(chunk['distance_ly'] > 0) & (chunk['distance_ly'] <= max_dist)]

gs = len(x_range) - 1

if len(chunk) == 0:

return np.zeros((gs, gs, gs), dtype=np.float32), 0

ra_rad = np.radians(chunk[RA_COL].values)

dec_rad = np.radians(chunk[DEC_COL].values)

dist = chunk['distance_ly'].values

xs = dist * np.cos(dec_rad) * np.cos(ra_rad)

ys = dist * np.cos(dec_rad) * np.sin(ra_rad)

zs = dist * np.sin(dec_rad)

mask = (np.abs(xs) < max_dist) & (np.abs(ys) < max_dist) & (np.abs(zs) < max_dist)

xs, ys, zs = xs[mask], ys[mask], zs[mask]

if len(xs) == 0:

return np.zeros((gs, gs, gs), dtype=np.float32), 0

H, _ = np.histogramdd(

np.column_stack([xs, ys, zs]),

bins=(x_range, y_range, z_range),

)

return H.astype(np.float32), int(mask.sum())

# ╔══════════════════════════════════════════════════════════════╗

# ║ STREAMING CHUNK GENERATOR ║

# ╚══════════════════════════════════════════════════════════════╝

def chunk_generator(csv_path, x_range, y_range, z_range, max_dist):

"""Yields one chunk at a time — never loads full file into RAM."""

for chunk in pd.read_csv(

csv_path,

usecols=[RA_COL, DEC_COL, PAR_COL],

dtype={RA_COL: 'float32', DEC_COL: 'float32', PAR_COL: 'float32'},

chunksize=CHUNK_SIZE,

low_memory=False,

yield (chunk, x_range, y_range, z_range, max_dist)

# ╔══════════════════════════════════════════════════════════════╗

# ║ MAIN ║

# ╚══════════════════════════════════════════════════════════════╝

if __name__ == '__main__':

print("Script started!")

t0 = time.time()

print("=" * 65)

print(" 3D Stellar Density Isosurface Radial Velocity — Streaming 33M Stars")

print("=" * 65)

print(f" Files: {CSV_FILES}")

print(f" Max dist: {MAX_DIST_LY:,} ly")

print(f" Grid: {GRID_SIZE}³ = {GRID_SIZE**3:,} cells")

print(f" Cores: {N_CORES}")

print(f" Chunk size: {CHUNK_SIZE:,}")

print("=" * 65)

# ── Build grid edges ──────────────────────────────────────

lim = MAX_DIST_LY + 5

x_range = np.linspace(-lim, lim, GRID_SIZE)

y_range = np.linspace(-lim, lim, GRID_SIZE)

z_range = np.linspace(-lim, lim, GRID_SIZE)

H = np.zeros((GRID_SIZE - 1, GRID_SIZE - 1, GRID_SIZE - 1), dtype=np.float32)

total_stars = 0

# ── Stream & process each file ────────────────────────────

for csv_path in CSV_FILES:

if not os.path.exists(csv_path):

print(f"\nWARNING: File not found — {csv_path} (skipping)")

continue

file_size_gb = os.path.getsize(csv_path) / 1e9

print(f"\nStreaming: {csv_path} ({file_size_gb:.2f} GB)")

file_stars = 0

chunk_count = 0

with mp.Pool(processes=N_CORES) as pool:

gen = chunk_generator(csv_path, x_range, y_range, z_range, MAX_DIST_LY)

for h_part, count in pool.imap(process_chunk_worker, gen, chunksize=1):

H += h_part

file_stars += count

chunk_count += 1

if chunk_count % 10 == 0:

elapsed = time.time() - t0

rate = file_stars / elapsed if elapsed > 0 else 0

print(f" Chunk {chunk_count:>5} | Stars: {file_stars:,} | "

f"{elapsed:.0f}s | {rate/1e6:.2f}M stars/sec")

print(f" File total: {file_stars:,} stars")

total_stars += file_stars

print(f"\n{'='*65}")

print(f"All files loaded. Total valid stars: {total_stars:,}")

print(f"Elapsed: {(time.time()-t0)/60:.1f} min")

# ── Smooth ────────────────────────────────────────────────

print(f"\nApplying Gaussian smoothing (sigma={SIGMA})...")

H_smooth = gaussian_filter(H, sigma=SIGMA)

del H

d_min, d_max, d_mean = H_smooth.min(), H_smooth.max(), H_smooth.mean()

print(f"Density stats: min={d_min:.4f}, max={d_max:.4f}, mean={d_mean:.4f}")

print(f"Non-zero cells: {np.sum(H_smooth > 0):,} / {H_smooth.size:,}")

# ── Diagnostic: top 20 densest cells ─────────────────────

print("\n── Top 20 Densest Grid Cells ──")

x_centers = (x_range[:-1] + x_range[1:]) / 2

y_centers = (y_range[:-1] + y_range[1:]) / 2

z_centers = (z_range[:-1] + z_range[1:]) / 2

flat_idx = np.argsort(H_smooth.ravel())[-20:][::-1]

ix, iy, iz = np.unravel_index(flat_idx, H_smooth.shape)

print(f"{'Rank':<5} {'Density':<10} {'X(ly)':<9} {'Y(ly)':<9} {'Z(ly)':<9}"

f" {'RA(deg)':<9} {'Dec(deg)':<10} {'Dist(ly)':<9}")

for rank, (i, j, k) in enumerate(zip(ix, iy, iz), 1):

cx, cy, cz = x_centers[i], y_centers[j], z_centers[k]

dist_c = np.sqrt(cx**2 + cy**2 + cz**2)

ra_d = np.degrees(np.arctan2(cy, cx)) % 360

dec_d = np.degrees(np.arcsin(np.clip(cz / dist_c, -1, 1))) if dist_c > 0 else 0

print(f"{rank:<5} {H_smooth[i,j,k]:<10.2f} {cx:<9.1f} {cy:<9.1f} {cz:<9.1f}"

f" {ra_d:<9.1f} {dec_d:<10.1f} {dist_c:<9.1f}")

print("\nHint: Sco-Cen ~ RA 269, Dec -35 | Orion OB1 ~ RA 84, Dec 0")

print(" Local Bubble boundary ~ 300-1000 ly | Pleiades ~ RA 56, Dec +24\n")

# ── PyVista grid ──────────────────────────────────────────

print("Building PyVista grid...")

grid = pv.ImageData()

grid.dimensions = np.array(H_smooth.shape)

spacing_val = (2 * lim) / (GRID_SIZE - 1)

grid.spacing = (spacing_val, spacing_val, spacing_val)

grid.origin = (-lim, -lim, -lim)

grid.point_data['density'] = H_smooth.flatten(order='F')

# ── Auto-scaled thresholds ────────────────────────────────

RV_THRESHOLD = d_max * 0.02

thresholds = [

(d_max * 0.005, 'darkblue', 0.15, 'Ultra sparse (0.5%)'),

(d_max * 0.01, 'blue', 0.20, 'Very sparse (1%)'),

(d_max * 0.02, 'cyan', 0.30, 'Sparse (2%)'),

(d_max * 0.05, 'green', 0.45, 'Medium (5%)'),

(d_max * 0.10, 'yellow', 0.55, 'Dense (10%)'),

(d_max * 0.20, 'orange', 0.70, 'Very dense (20%)'),

(d_max * 0.40, 'red', 0.85, 'Maximum (40%)'),

]

print(f"Auto-scaled thresholds (max density = {d_max:.2f}):")

for t in thresholds:

print(f" {t[3]}: {t[0]:.4f}")

# ── Plotter ───────────────────────────────────────────────

plotter = pv.Plotter()

plotter.set_background('black')

surfaces_added = 0

for threshold, color, opacity, label in thresholds:

try:

contour = grid.contour([threshold], scalars='density')

if contour.n_points > 0:

plotter.add_mesh(contour, color=color, opacity=opacity,

show_edges=False, smooth_shading=True, label=label)

surfaces_added += 1

print(f" Surface [{label}] @ {threshold:.4f}: {contour.n_points:,} points")

else:

print(f" No surface at {threshold:.4f}")

except Exception as e:

print(f" Failed at {threshold:.4f}: {e}")

print(f"Total surfaces added: {surfaces_added}")

# ── Accumulate all 3 vector components ───────────────────────

RV_vx = np.zeros((GRID_SIZE-1,)*3, dtype=np.float32)

RV_vy = np.zeros((GRID_SIZE-1,)*3, dtype=np.float32)

RV_vz = np.zeros((GRID_SIZE-1,)*3, dtype=np.float32)

RV_count = np.zeros((GRID_SIZE-1,)*3, dtype=np.float32)

for csv_path in CSV_FILES:

chunk_num = 0

for chunk in pd.read_csv(

csv_path,

usecols=[RA_COL, DEC_COL, PAR_COL, RV_COL],

dtype={RA_COL:'float32', DEC_COL:'float32',

PAR_COL:'float32', RV_COL:'float32'},

chunksize=CHUNK_SIZE,

low_memory=False,

chunk = chunk.dropna(subset=[RA_COL, DEC_COL, PAR_COL, RV_COL])

chunk = chunk[chunk[PAR_COL] > 0]

chunk['distance_ly'] = 3262.0 / chunk[PAR_COL]

chunk = chunk[np.isfinite(chunk['distance_ly'])]

chunk = chunk[(chunk['distance_ly'] > 0) & (chunk['distance_ly'] <= MAX_DIST_LY)]

if len(chunk) == 0:

continue

ra_rad = np.radians(chunk[RA_COL].values)

dec_rad = np.radians(chunk[DEC_COL].values)

dist = chunk['distance_ly'].values

rv = chunk[RV_COL].values

xs = dist * np.cos(dec_rad) * np.cos(ra_rad)

ys = dist * np.cos(dec_rad) * np.sin(ra_rad)

zs = dist * np.sin(dec_rad)

# Line-of-sight unit vector scaled by radial velocity

norm = np.maximum(dist, 1e-6)

vx = (xs / norm) * rv

vy = (ys / norm) * rv

vz = (zs / norm) * rv

gs = GRID_SIZE - 1

xi = np.clip(np.searchsorted(x_range, xs) - 1, 0, gs-1)

yi = np.clip(np.searchsorted(y_range, ys) - 1, 0, gs-1)

zi = np.clip(np.searchsorted(z_range, zs) - 1, 0, gs-1)

np.add.at(RV_vx, (xi, yi, zi), vx)

np.add.at(RV_vy, (xi, yi, zi), vy)

np.add.at(RV_vz, (xi, yi, zi), vz)

np.add.at(RV_count, (xi, yi, zi), 1)

chunk_num += 1

if chunk_num % 10 == 0:

print(f" RV chunk {chunk_num}")

# ── Mean velocity per voxel ───────────────────────────────────

valid_cells = RV_count > 0

RV_vx[valid_cells] /= RV_count[valid_cells]

RV_vy[valid_cells] /= RV_count[valid_cells]

RV_vz[valid_cells] /= RV_count[valid_cells]

# ── Build arrow positions and vectors ────────────────────────

x_centers = (x_range[:-1] + x_range[1:]) / 2

y_centers = (y_range[:-1] + y_range[1:]) / 2

z_centers = (z_range[:-1] + z_range[1:]) / 2

# Apply density threshold + stride

gs = GRID_SIZE - 1

ix = np.arange(0, gs, ARROW_STRIDE)

iy = np.arange(0, gs, ARROW_STRIDE)

iz = np.arange(0, gs, ARROW_STRIDE)

IX, IY, IZ = np.meshgrid(ix, iy, iz, indexing='ij')

IX, IY, IZ = IX.ravel(), IY.ravel(), IZ.ravel()

density_vals = H_smooth[IX, IY, IZ]

mask = density_vals > RV_THRESHOLD

IX, IY, IZ = IX[mask], IY[mask], IZ[mask]

arrow_x = x_centers[IX]

arrow_y = y_centers[IY]

arrow_z = z_centers[IZ]

arrow_vx = RV_vx[IX, IY, IZ]

arrow_vy = RV_vy[IX, IY, IZ]

arrow_vz = RV_vz[IX, IY, IZ]

print(f"Arrows to render: {len(arrow_x):,}")

# ── Add to plotter ────────────────────────────────────────────

arrow_points = np.column_stack([arrow_x, arrow_y, arrow_z])

arrow_vectors = np.column_stack([arrow_vx, arrow_vy, arrow_vz])

# Color by RV magnitude (+ = receding, - = approaching)

rv_magnitude = np.sqrt(arrow_vx**2 + arrow_vy**2 + arrow_vz**2)

pdata = pv.PolyData(arrow_points)

pdata['vectors'] = arrow_vectors

pdata['rv_speed'] = rv_magnitude

arrows = pdata.glyph(orient='vectors', scale='rv_speed',

factor=80, # scale arrow size — adjust as needed

geom=pv.Arrow())

plotter.add_mesh(arrows, scalars='rv_speed', cmap='coolwarm',

show_scalar_bar=True, scalar_bar_args={

'title': 'Radial Velocity (km/s)',

'color': 'white'

})

print("Vector field added!")

# ── Annotations ───────────────────────────────────────────

plotter.add_text(

f'3D Stellar Density Isosurfaces Radial Velocity\n{total_stars:,} Stars | GAIA DR3',

position='upper_edge', font_size=12, color='white'

)

plotter.add_text(

'Thin shells near Earth = Stellar Desert\nThick shells at distance = Dense regions',

position='lower_left', font_size=9, color='white'

)

plotter.show_axes()

# ── Earth marker ──────────────────────────────────────────

origin_sphere = pv.Sphere(radius=MAX_DIST_LY * 0.012, center=(0, 0, 0))

plotter.add_mesh(origin_sphere, color='white', opacity=0.9)

plotter.add_point_labels(

[[0, 0, 0]], ['Earth'], font_size=12,

text_color='white', point_color='white',

point_size=0, always_visible=True, shape_opacity=0

)

# ── Legend ────────────────────────────────────────────────

legend_entries = [

['Ultra sparse (0.5%)', 'darkblue'],

['Very sparse (1%)', 'blue'],

['Sparse (2%)', 'cyan'],

['Medium (5%)', 'green'],

['Dense (10%)', 'yellow'],

['Very dense (20%)', 'orange'],

['Maximum (40%)', 'red'],

]

plotter.add_legend(legend_entries, bcolor=(0.1, 0.1, 0.1),

border=True, loc='center left', size=(0.18, 0.22))

# ── Show ──────────────────────────────────────────────────

# ── Show settings ─────────────────────────────────────────

INTERACTIVE = True

MAKE_VIDEO = True

plotter.camera_position = 'iso'

plotter.camera.zoom(1.2)

if INTERACTIVE:

plotter.show()

if MAKE_VIDEO:

# Rebuild plotter for video (PyVista closes renderer after show())

plotter2 = pv.Plotter(off_screen=True)

plotter2.set_background('black')

# Re-add isosurfaces

for threshold, color, opacity, label in thresholds:

try:

contour = grid.contour([threshold], scalars='density')

if contour.n_points > 0:

plotter2.add_mesh(contour, color=color, opacity=opacity,

show_edges=False, smooth_shading=True)

except:

pass

# Re-add arrows

plotter2.add_mesh(arrows, scalars='rv_speed', cmap='coolwarm',

show_scalar_bar=True, scalar_bar_args={

'title': 'Radial Velocity (km/s)',

'color': 'white'

})

# Re-add annotations

plotter2.add_text(

f'3D Stellar Density Isosurfaces Radial Velocity\n{total_stars:,} Stars | GAIA DR3',

position='upper_edge', font_size=12, color='white'

)

plotter2.add_text(

'Thin shells near Earth = Stellar Desert\nThick shells at distance = Dense regions',

position='lower_left', font_size=9, color='white'

)

plotter2.show_axes()

# Re-add Earth marker

origin_sphere = pv.Sphere(radius=MAX_DIST_LY * 0.012, center=(0, 0, 0))

plotter2.add_mesh(origin_sphere, color='white', opacity=0.9)

plotter2.add_point_labels(

[[0, 0, 0]], ['Earth'], font_size=12,

text_color='white', point_color='white',

point_size=0, always_visible=True, shape_opacity=0

)

# Re-add legend

legend_entries = [

['Ultra sparse (0.5%)', 'darkblue'],

['Very sparse (1%)', 'blue'],

['Sparse (2%)', 'cyan'],

['Medium (5%)', 'green'],

['Dense (10%)', 'yellow'],

['Very dense (20%)', 'orange'],

['Maximum (40%)', 'red'],

]

plotter2.add_legend(legend_entries, bcolor=(0.1, 0.1, 0.1),

border=True, loc='center left', size=(0.18, 0.22))

# Video

plotter2.camera_position = 'iso'

plotter2.camera.zoom(1.2)

plotter2.show(auto_close=False, interactive=False)

print("Creating rotation + zoom-out video...")

plotter2.open_movie('isosurface_radial_velocity_33M_rotation.mp4', framerate=30)

plotter2.render()

n_frames_zoom = 360

path_zoom = plotter2.generate_orbital_path(n_points=n_frames_zoom, shift=0, viewup=[0,0,1], factor=2.5)

plotter2.camera.zoom(2.5)

zoom_per_frame = 1.0 - (1.5 / n_frames_zoom)

for i in range(n_frames_zoom):

plotter2.camera.position = path_zoom.points[i]

plotter2.camera.zoom(zoom_per_frame)

plotter2.write_frame()

n_frames_full = 180 * 3

path_full = plotter2.generate_orbital_path(n_points=n_frames_full, shift=0, viewup=[0,0,1], factor=2.5)

for i in range(n_frames_full):

plotter2.camera.position = path_full.points[i]

plotter2.write_frame()

plotter2.close()

print("Video saved!")

total_time = time.time() - t0

print(f"\n{'='*65}")

print(f" Done! Total runtime: {total_time/60:.1f} minutes")

print(f" Stars: {total_stars:,}")

print(f" Grid: {GRID_SIZE}³ = {GRID_SIZE**3:,} cells")

print(f" Surfaces: {surfaces_added}")

print("=" * 65)

Supplies

Python
pandas
numpy
scipy
pyvista
multiprocessing
imageio
